074_SCOPE CYCLING
SCOPE R4 RIM BRAKE
SCOPE R4 RIM BRAKE
SKU:SC2021055
Couldn't load pickup availability
Developed in The Netherlands
We develop our wheels in-house without any compromise to achieve the perfect balance between aerodynamics, weight, stiffness and durability. Each single detail of our wheels is developed from our headquarters in The Netherlands.
Optimized Aerodynamics
The rim profile of our wheels is developed using our Algorithm Enhanced Aerodynamics (AEA) technology. This algorithm calculates the most aerodynamic rim profile to ensure optimum performance.
Ultra-light and durable
The hubs feature our Diamond hardened Ratchet engagement System for direct engagement, improved durability, and a significant reduction in weight.
Perfect tire fit
The unique geometry of our Scope Tubeless System ensures easy mounting, direct inflation, long-lasting pressure and compatibility with all (tubeless) tires.
Lightweight
With our Local Reinforcement carbon technology we increase the number of carbon layers only around the spoke holes on the inside of the rim. This way we significantly reduce its weight, while preserving the strength and stiffness.
Included:
- 10spd spacer ring (Shimano free hub)
- Product registration card
- Tubeless rim tape – pre-installed
- Scope QR Axles
Specifications
General
Weight
1485g
Maximum rider weight
No weight limit
Rims (Tubeless) *
Rim Height
45mm
External Rim Width
28mm
Internal Rim Width
21mm
* Compatible with all clincher tires in combination with inner-tubes.
Front Hubs
Hubs
Scope R-series
Bearings
2 X 61803
Axle
9mm QR Axle
Brake interface
Rim Brake
Rear Hubs
Hubs
Scope R-series
Bearings
61803 + 61903
Axle
9mm QR Axle *
Brake interface
Rim Brake
* Special end-caps available for different axle configurations
Spokes
Spoke count front
21
Spoke count rear
24
Spoke type
Sapim CX - Ray
